Запчасти Komatsu PC300-8M0 ЦИЛИНДР РУКОЯТИ( ЧАС. СМАЗКА INTERVAL) (ДЛЯ .M РУКОЯТЬ) T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

-

707-01-XYS11

CYLINDER GROUP

|$2

707-01-XEC11

CYLINDER GROUP

1

721-13-16251

CYLINDER

2

721-58-11360

ROD

3

707-76-10130

BUSHING

4

07145-00100

SEAL, DUST\((KIT)\)

5

707-76-10130

BUSHING

6

07145-00100

SEAL, DUST\((KIT)\)

7

07020-00000

FITTING, GREASE

8

707-71-32800

COLLAR

9

707-35-91640

RING, BACK-UP\((KIT)\)

10

07000-15150

O-RING\((KIT)\)

11

707-71-61130

PLUNGER

12

707-71-70290

PLUNGER

13

04260-00635

BALL, STEEL

14

707-71-91270

CAP

15

721-27-16571

HEAD

16

07179-13126

RING, SNAP

17

198-63-94170

SEAL, DUST\((KIT)\)

18

707-51-11030

PACKING, ROD\((KIT)\)

19

707-51-11650

RING, BUFFER\((KIT)\)

20

707-52-90851

BUSHING

21

07000-15150

O-RING\((KIT)\)

22

707-35-91640

RING, BACK-UP\((KIT)\)

23

01010-82085

BOLT

24

707-88-75310

WASHER

25

707-75-11040

RING SMAP

26

707-36-16580

PISTON

27

707-44-161890

RING PISTON (KIT)

28

707-39-16120

RING WEAR (KIT)

29

707-44-16150

RING

30

07000-85100

O-RING\((KIT)\)

31

07001-05100

RING, BACK-UP\((KIT)\)

32

01310-01216

SCREW

33

707-83-13010

VAVLE

34

07750-01628

SPRING

35

707-87-14070

PLUG

36

07002-12034

O-RING\((KIT)\)

37

707-88-33040

CAP

38

07371-31049

FLANGE,SPLIT
