Запчасти Komatsu PC300-8M0 ЦИЛИНДР СТРЕЛЫ(MM УСИЛ. СТРЕЛА, ЧАС. СМАЗКА INTERVAL) (ЛЕВ.) T [РАБОЧЕЕ ОБОРУДОВАНИЕ]

-

707-E1-X0681

CYLINDER ASSEMBLY

1

721-13-14050

CYLINDER

2

721-58-10400

ROD, PISTON

3

707-76-90490

BUSHING

4

07145-00090

SEAL, DUST\((K12)\)

5

07020-00000

FITTING, GREASE

6

07043-00108

PLUG, TAPER

7

707-76-10290

BUSHING

8

07145-00100

SEAL, DUST\((K12)\)

9

707-71-35220

COLLAR

10

707-35-31310

RING, BACK-UP\((K12)\)

11

07000-B5130

O-RING\((K12)\)

12

707-71-71060

PLUNGER

13

707-27-14690

HEAD, CYLINDER

14

707-56-10740

SEAL, DUST\((K12)\)

15

07179-13114

RING, SNAP

16

707-52-90781

BUSHING

17

707-51-10860

PACKING, ROD\((K12)\)

18

707-51-10650

RING, BUFFER\((K12)\)

19

707-35-31310

RING, BACK-UP\((K12)\)

20

07000-B5130

O-RING\((K12)\)

21

01010-81875

BOLT

22

707-41-11840

WASHER

23

707-75-10160

RING, SNAP

24

707-36-14650

PISTON

25

707-44-14150

RING, PISTON\((K12)\)

26

707-39-14110

RING, WEAR\((K12)\)

27

707-35-30900

RING, BACK-UP\((K12)\)

28

07000-B5090

O-RING\((K12)\)

29

707-44-14910

RING

30

01310-01216

SCREW

31

707-86-00810

TUBE

32

707-86-00860

TUBE

33

707-87-14700

PLUG

34

07002-63034

O-RING\((K12)\)

35

207-63-54590

BRACKET

36

07372-21060

BOLT

37

01643-51032

WASHER

38

07000-B3035

O-RING\((K12)\)

39

707-88-21370

BAND
