Запчасти Komatsu PC300-8 СИСТЕМА ОХЛАЖДЕНИЯ РАДИАТОР И МАСЛООХЛАДИТЕЛЬ (№C-) СИСТЕМА ОХЛАЖДЕНИЯ

1

207-03-75120

Radiator Assembly

2

20Y-03-22110

Cap

3

205-03-71230

Hose

4

20Y-03-11330

Clip

5

205-03-62660

Plug

6

07000-11007

O-ring

7

208-03-71730

Seal

8

208-03-71810

Seal

9

208-03-71840

Seal

10

201-03-29160

Spacer

11

07002-12434

O-ring

12

201-910-6730

Cushion

13

207-03-75590

Plate

14

01010-81045

Bolt

15

01643-31032

Washer

16

207-03-75171

Frame

17

207-03-75181

Frame

18

207-03-76340

Frame

19

01010-81225

Bolt

20

01643-31232

Washer

21

207-03-76350

Frame

22

01010-81030

Bolt

23

01643-31032

Washer

24

01010-81020

Bolt

25

01643-31032

Washer

26

22B-03-12590

Cushion

27

208-03-71380

Cushion

28

208-03-71480

Seal

29

208-03-71490

Seal

30

208-03-71780

Seal

31

207-03-76410

Seal

32

208-03-71821

Seal

33

208-03-71830

Seal

34

207-03-76320

Oil Cooler Assembly

35

207-03-76330

Frame

36

207-03-76380

Seal

37

207-03-76390

Seal

38

207-03-76420

Seal

39

208-03-71131

Oil Cooler

40

208-03-71690

Seal

41

208-03-71850

Seal

42

208-03-71860

Seal

43

208-03-71870

Seal

44

208-03-71890

Seal

45

01010-81020

Bolt

46

01643-31032

Washer

47

01010-81240

Bolt

48

01643-31232

Washer

49

07000-13045

O-ring

50

01010-81030

Bolt

51

01643-31032

Washer

52

01010-81225

Bolt

53

01643-31232

Washer
