Запчасти Komatsu PC300-8 ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (8/) (№77-) ПОРШЕНЬ НАСОС

|$0

708-2G-00150

Pump Assembly

|$1

708-2G-01150

Pump Subassembly

1

708-2G-14120

Slider

1

708-2G-03640

Valve Assembly

1

708-2G-03650

Piston Assembly

2

Piston Assembly

3

Plug

4

Seal

5

Plug

6

708-2L-35760

Ball

7

708-2L-35770

Plug

8

Seal

9

708-2L-35170

Pin

10

708-2G-15211

Spool

11

708-2G-15290

Retainer

12

708-2G-15140

Seat

13

708-2G-15270

Spring

14

708-2G-15280

Spring

15

708-2G-15151

Seat

16

708-2G-15250

Spring

17

708-2G-14340

Screw

18

07000-B3038

O-ring

19

708-2G-15230

Ring, Back-up

20

Seal

21

708-2G-15240

Plug

22

07000-B2012

O-ring

23

07000-B2050

O-ring

24

708-2G-15310

Ring, Back-up

25

708-2G-14190

Cover

26

01580-10806

Nut

27

708-2L-35290

Nut

28

708-2G-15330

Ring, Wear

29

01252-61645

Bolt, Hexagon Socket Head
