Запчасти Komatsu PC300-8 ЦИЛИНДР СТРЕЛЫ, ЛЕВ. (№9-) ЦИЛИНДР СТРЕЛЫ, С ПРЕДОТВРАЩЕНИЕМ СМЕЩЕНИЯ КЛАПАН

|$0

707-01-0A431

Cylinder Assembly

1

707-13-14581

Cylinder

2

707-58-10720

Rod

3

707-76-90490

Bushing

4

07145-00090

Seal, Dust, (Kit : K05)

5

07020-00000

Fitting, Grease

6

07043-00108

Plug, Taper

7

707-76-10290

Bushing

8

07145-00100

Seal, Dust, (Kit : K05)

9

707-71-34800

Collar

10

707-35-91420

Ring, Back-up, (Kit : K05)

11

07000-15130

O-ring, (Kit : K05)

12

707-71-61090

Plunger

13

707-27-14890

Head

14

707-56-10740

Seal, Dust, (Kit : K05)

15

07179-13114

Ring, Snap

16

707-51-10030

Packing, Rod, (Kit : K05)

17

707-51-10640

Ring, Buffer, (Kit : K05)

18

707-52-90780

Bushing

19

07000-15130

O-ring, (Kit : K05)

20

707-35-91420

Ring, Back-up, (Kit : K05)

21

01010-81875

Bolt

22

707-41-11840

Washer

23

707-75-10160

Ring, Snap

24

707-36-14650

Piston

25

707-44-14180

Ring, Piston, (Kit : K05)

26

707-39-14110

Ring, Wear, (Kit : K05)

27

707-44-14910

Ring

28

07000-15090

O-ring, (Kit : K05)

29

07001-05090

Ring, Back-up, (Kit : K05)

30

01310-01216

Screw

31

707-86-11580

Tube

32

207-63-54590

Bracket

33

07372-21060

Bolt

34

01643-51032

Washer

35

07000-13035

O-ring, (Kit : K05)

36

707-88-21370

Band

37

07372-21240

Bolt

38

01643-51232

Washer

39

07283-33442

Clip, Pipe

40

01597-01009

Nut

41

01643-31032

Washer

42

07371-31049

Flange, Split

43

707-88-33040

Cap

44

07372-21035

Bolt

45

01643-51032

Washer
