Запчасти Komatsu PC300-7E0 ЦИЛИНДР КОВША (ДЛЯ .M И .M РУКОЯТЬ) ( ЧАС. СИСТ. СМАЗКИ ТИП)(№787-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XS731

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0H771

BUCKET CYLINDER A.

1

707-13-14591

CYLINDER

2

707-76-90490

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-58-10730

ROD

6

207-63-76170

BUSHING

7

207-70-72120

SEAL,DUST (KIT)

8

07020-00000

FITTING,GREASE

9

707-27-14690

HEAD

10

176-63-56170

SEAL,DUST (KIT)

11

07179-13114

RING,SNAP

12

707-52-90780

BUSHING

13

707-75-10160

RING,SNAP

14

707-51-10030

PACKING,ROD (KIT)

15

707-51-10640

RING,BUFFER (KIT)

16

707-35-91420

RING,BACK-UP (KIT)

17

07000-15130

O-RING (KIT)

18

01010-81875

BOLT

19

707-41-11840

WASHER

20

707-36-14650

PISTON

21

01310-01216

SCREW

22

707-44-14180

RING,PISTON (KIT)

23

707-39-14110

RING,WEAR (KIT)

24

707-44-14910

RING

25

07001-05090

RING,BACK-UP (KIT)

26

07000-15090

O-RING (KIT)

27

707-86-11621

TUBE

28

207-63-73180

TUBE

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-13035

O-RING (KIT)

32

207-63-73790

BRACKET

33

707-88-21410

BAND

34

07372-21240

BOLT

35

01643-51232

WASHER

36

707-88-10150

CLAMP

37

01010-81245

BOLT

38

01643-31232

WASHER

39

707-88-33040

CAP

40

07371-31049

FLANGE,SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER

|$47

707-99-58090

SERVICE KIT
