Запчасти Komatsu PC300-7 ЦИЛИНДР СТРЕЛЫ(ДЛЯ ЧАС. СИСТЕМА СМАЗКИ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XX481

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XX491

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0E231

BOOM CYLINDER ASS'Y

1

707-13-14580

CYLINDER

2

707-76-90490

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

07043-00108

PLUG

6

707-58-10720

ROD

7

707-76-10290

BUSHING

8

07145-00100

SEAL,DUST (KIT)

9

707-71-34800

COLLAR

10

707-35-91420

RING,BACK-UP (KIT)

11

07000-15130

O-RING (KIT)

12

707-71-61090

PLUNGER

13

707-27-14890

HEAD

14

176-63-56170

SEAL,DUST (KIT)

15

07179-13114

RING,SNAP

16

707-52-90780

BUSHING

17

707-51-10030

PACKING,ROD (KIT)

18

707-51-10640

RING,BUFFER (KIT)

19

707-35-91420

RING,BACK-UP (KIT)

20

07000-15130

O-RING (KIT)

21

01010-81875

BOLT

22

707-41-11840

WASHER

23

707-36-14650

PISTON

24

01310-01216

SCREW

25

707-44-14180

RING,PISTON (KIT)

26

707-39-14110

RING,WEAR (KIT)

27

707-44-14910

RING

28

07001-05090

RING,BACK-UP (KIT)

29

07000-15090

O-RING (KIT)

30

707-81-14030

SPACER

31

707-39-14110

RING,WEAR (KIT)

32

707-86-11580

TUBE,L.H.

32

707-86-11590

TUBE,R.H.

33

207-63-54580

TUBE,L.H.

33

207-63-54680

TUBE,R.H.

34

07372-21060

BOLT

35

01643-51032

WASHER

36

07000-13035

O-RING (KIT)

37

207-63-54590

BRACKET

38

707-88-21370

BAND

39

07372-21240

BOLT

40

01643-51232

WASHER

41

07283-33442

CLIP

42

01643-31032

WASHER

43

01597-01009

NUT

44

01010-81025

BOLT

45

01643-31032

WASHER

46

707-88-33040

CAP

47

07371-31049

FLANGE,SPLIT

48

07372-21035

BOLT

49

01643-51032

WASHER

|$58

707-99-58030

SERVICE KIT
