Запчасти Komatsu PC300-6Z ЦИЛИНДР КОВША(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

207-63-X9040

BUCKET CYLINDER G.

G-1

207-63-X2531

BUCKET CYLINDER G.

|1

207-63-02531

BUCKET CYLINDER A.

1

207-63-73341

CYLINDER

2

707-76-90130

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

207-63-73320

ROD

6

207-63-76170

BUSHING

7

207-70-72120

SEAL,DUST (KIT)

|7

205-70-62180

SEAL,DUST (KIT)

8

07020-00000

FITTING,GREASE

9

707-27-14930

HEAD

10

176-63-56170

SEAL,DUST (KIT)

11

07179-13114

RING,SNAP

12

707-52-90780

BUSHING

13

707-51-10030

PACKING,ROD (KIT)

14

707-51-10630

RING,BUFFER (KIT)

15

707-35-91420

RING,BACK-UP (KIT)

16

07000-15130

O-RING (KIT)

17

01010-81875

BOLT

18

707-41-11840

WASHER

19

707-36-14410

PISTON

20

01310-01216

SCREW

21

707-44-14180

RING,PISTON (KIT)

22

707-39-14820

RING,WEAR (KIT)

23

707-44-14910

RING

24

07001-05090

RING,BACK-UP (KIT)

25

07000-15090

O-RING (KIT)

26

207-63-73371

TUBE

27

207-63-73180

TUBE

28

01435-01055

BOLT

29

07000-13035

O-RING (KIT)

30

707-88-87180

BRACKET

31

707-88-87170

BAND

32

01010-81240

BOLT

33

01643-51232

WASHER

34

707-88-10150

CLAMP

35

01010-81245

BOLT

36

01643-31232

WASHER

37

07000-13032

O-RING

38

07378-11000

HEAD

39

07371-31049

FLANGE,SPLIT

40

07372-21035

BOLT

41

01643-51032

WASHER

|K

707-99-58370

SERVICE KIT
