Запчасти Komatsu PC300-6 ОСНОВН. КЛАПАН (/) РЕМ. КОМПЛЕКТЫ

|$1

723-47-18100

CONTROL VALVE

|$2

723-47-18101

CONTROL VALVE

|$3

723-46-06800

BODY SUB ASS'Y

|$4

723-46-06802

BODY SUB ASS'Y

1

BLOCK

2

SPOOL

3

SPOOL

4

SPOOL

5

SPOOL

6

SPOOL

7

723-46-15130

PLUG

8

723-46-15650

PLUG

9

723-46-15140

PLUG

10

07002-10823

O-RING

11

708-7T-16460

BALL

12

723-46-15120

RETAINER

13

723-46-15880

RETAINER

14

723-46-14110

SPRING

15

723-46-14170

SPRING

16

723-46-14250

SPRING

17

723-46-15620

RETAINER

18

723-46-15610

CASE

19

723-46-14210

SPRING

20

723-46-14220

SPRING

21

723-46-15630

PLUG

22

709-25-11390

O-RING

23

723-46-15640

PISTON

24

702-73-11510

SEAL

25

723-46-16210

RETAINER

26

723-46-15110

CASE

27

07430-71380

O-RING

28

01252-60820

BOLT

29

723-46-15410

CASE

30

723-46-15420

RETAINER

31

723-46-15450

PLUG

32

07002-13034

O-RING

33

723-46-15440

SPRING

34

723-46-15430

PISTON

35

PLUG

36

723-46-15150

VALVE

37

723-46-14150

SPRING
