Запчасти Komatsu PC300-6 МОТОР ПОВОРОТА (/) РЕМ. КОМПЛЕКТЫ

|$1

706-77-01271

MOTOR

|$2

706-77-03130

MOTOR SUB ASS'Y

1

Ѓљ706-77-43210

CASE

2

Ѓљ706-77-72610

HOUSING

3

Ѓљ706-75-42830

PIN

4

706-77-72170

PLUG

5

07002-12434

O-RING

5A

706-73-71450

PLUG

5B

07002-11423

O-RING

6

Ѓљ706-77-40010

BEARING

7

Ѓљ706-7E-11440

O-RING

8

Ѓљ706-77-43180

BOLT

9

Ѓљ706-77-43860

SHAFT

10

Ѓљ706-77-43880

BEARING

11

Ѓљ706-77-42890

BEARING

12

Ѓљ706-77-42051

SPRING

13

Ѓљ706-77-42041

SEAT

14

Ѓљ706-77-05010

SPACER

15

Ѓљ04064-06525

SNAP RING

16

706-77-43950

OIL SEAL

17

706-77-43060

COVER

18

07000-02125

O-RING

19

04071-00130

SNAP RING

20

Ѓљ706-77-43191

CYLINDER BLOCK

21

Ѓљ706-77-43840

PLATE

22

Ѓљ708-18-13230

PIN

23

Ѓљ706-77-43080

SHAFT

24

Ѓљ706-77-42130

RING

25

Ѓљ706-77-42110

SPRING

|$30

Ѓљ706-77-05050

RETAINER

26

RETAINER

27

SCREW

28

Ѓљ706-77-42160

PISTON

29

Ѓљ706-77-91540

PLATE

30

Ѓљ706-77-91550

DISC

31

Ѓљ706-77-91580

PISTON

32

Ѓљ07000-15180

O-RING

33

Ѓљ708-8H-15220

O-RING

34

Ѓљ706-77-91510

SPRING
