Запчасти Komatsu PC300-6 ОСНОВН. КОНСТРУКЦИЯ (PPC ЛИНИЯ ХОДА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

08017-32810

CONDUIT

2

08034-00536

BAND

3

20Y-62-27121

HOSE, 2950MM

4

207-62-62731

HOSE, 3000MM

5

207-62-62741

HOSE, 3050MM

6

20Y-62-22790

BAND, RED, RED

7

20Y-62-22820

BAND, BLUE, BLUE

8

20Y-62-22850

BAND, GREEN, GREEN

9

20Y-62-22790

BAND, RED, RED

10

20Y-62-22820

BAND, BLUE, BLUE

11

20Y-62-22872

HOSE, 1350MM

12

203-62-52340

HOSE, 1000MM

13

08034-00519

BAND

14

20Y-62-18910

BOLT

15

07000-12018

O-RING

16

20Y-62-18890

BOLT

17

07000-12015

O-RING

18

07235-10210

ELBOW

19

07002-11423

O-RING

20

20Y-62-27770

CLAMP

21

01010-81020

BOLT

22

01643-31032

WASHER

23

201-62-72570

CLAMP

24

01010-81016

BOLT

25

01643-31032

WASHER

26

08034-00536

BAND

27

20Y-62-15831

BLOCK

28

01010-81045

BOLT

29

01643-31032

WASHER

30

07235-10311

ELBOW

31

07235-10210

ELBOW

32

07002-01423

O-RING

33

07230-20210

UNION

34

07230-20210

UNION

35

07002-01423

O-RING

36

20Y-62-15831

BLOCK

37

01010-81045

BOLT

38

01643-31032

WASHER

39

07235-10311

ELBOW

40

07235-10210

ELBOW

41

07002-01423

O-RING

42

07230-20210

UNION

43

07230-20210

UNION

44

07002-01423

O-RING
