Запчасти Komatsu PC300-6 МОТОР ХОДА (/)(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

708-8H-00250

MOTOR ASS'Y

|$3

708-8H-00210

MOTOR ASS'Y

1

708-8H-31210

O-RING

2

07000-12012

O-RING

3

04020-01228

PIN

4

01252-62055

BOLT

5

01252-62095

BOLT

6

708-8H-32111

SHAFT

7

708-8H-32150

BEARING

8

708-8H-32140

BEARING

9

708-8H-05030

SPACER KIT

9

SPACER, 1.6MM

9

SPACER, 1.7MM

9

SPACER, 1.8MM

9

SPACER, 1.9MM

9

SPACER, 2.0MM

9

SPACER, 2.1MM

9

SPACER, 2.2MM

10

708-1F-12281

SEAL,OIL

11

708-8H-32160

SPACER

12

04065-07825

RING,SNAP

13

708-8H-33112

BLOCK,CYLINDER

14

708-8H-33220

PLATE,VALVE

15

708-18-13230

PIN

16

708-8H-33360

PIN

17

708-8H-33141

SPACER

18

708-7H-13150

SPRING

19

04065-06020

RING

20

708-8H-33512

RETAINER

21

708-8H-33340

RETAINER,SHOE

22

708-8H-33610

PISTON SUB ASS'Y

23

708-8H-33431

CAM,ROCKER

24

04260-02857

BALL

25

708-8H-34143

PISTON

26

708-8H-34151

SPRING

27

708-8K-14210

PLUG

28

07002-13334

O-RING

29

708-8H-35130

PLATE

30

708-8H-35120

DISC

31

708-8H-35141

PISTON,BRAKE

32

07000-15175

O-RING

33

07001-05175

RING,BACK-UP

34

07000-15195

O-RING

35

07001-05195

RING,BACK-UP

36

708-8H-35150

SPRING
