Запчасти Komatsu PC300-6 ОСНОВН. КЛАПАН (-АКТУАТОР) (/7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC300-6 - ОСНОВН. КЛАПАН (-АКТУАТОР) (/7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
27
27
28
28
28
29
30
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
27
27
28
28
28
29
30

Артикул

Название

Примечание

Количество

|1

723-49-18101

CONTROL VALVE

|1

723-49-18100

CONTROL VALVE

|1

723-49-16102

CONTROL VALVE

|1

723-49-16101

CONTROL VALVE

|1

723-49-16100

CONTROL VALVE

|1

BODY SUB ASS'Y

|1

BODY SUB ASS'Y

|1

723-46-42100

VALVE ASS'Y

1

SLEEVE

2

VALVE

3

SPRING

4

SEAL

5

700-93-11320

O-RING

6

723-46-41950

RING

7

07002-13634

O-RING

8

01252-60845

BOLT

9

01643-50823

WASHER

|10

723-46-48100

VALVE ASS'Y

10

SLEEVE

11

VALVE

12

SEAT

13

POPPET

14

PLUG

15

SCREW

16

NUT

17

NUT

18

SPRING

19

SPRING

20

PLATE

21

CAP

22

SEAL

23

SEAL

24

700-93-11320

O-RING

25

723-46-41950

RING

26

07002-13634

O-RING

27

O-RING

28

RING

29

O-RING

30

RING,BACK-UP

|1

723-49-18101

CONTROL VALVE

|1

723-49-18100

CONTROL VALVE

|1

723-49-16102

CONTROL VALVE

|1

723-49-16101

CONTROL VALVE

|1

723-49-16100

CONTROL VALVE

|1

BODY SUB ASS'Y

|1

BODY SUB ASS'Y

|1

723-46-42100

VALVE ASS'Y

1

SLEEVE

2

VALVE

3

SPRING

4

SEAL

5

700-93-11320

O-RING

6

723-46-41950

RING

7

07002-13634

O-RING

8

01252-60845

BOLT

9

01643-50823

WASHER

|10

723-46-48100

VALVE ASS'Y

10

SLEEVE

11

VALVE

12

SEAT

13

POPPET

14

PLUG

15

SCREW

16

NUT

17

NUT

18

SPRING

19

SPRING

20

PLATE

21

CAP

22

SEAL

23

SEAL

24

700-93-11320

O-RING

25

723-46-41950

RING

26

07002-13634

O-RING

27

O-RING

28

RING

29

O-RING

30

RING,BACK-UP

Выбрано товаров: 78
