Запчасти Komatsu PC300-2 ОСНОВНАЯ РАМА(№-8) ОСНОВНАЯ РАМА И КАБИНА

1

207-46-11262

FRAME

1

207-46-11261

FRAME

1

207-46-11371

FRAME,(FOR WRIST CONTROL)

2

195-57-11530

CATCHER

3

01220-40512

SCREW

4

01601-20513

WASHER,SPRING

5

09460-00000

LOCK

6

205-46-63310

BAR

7

01643-31032

WASHER

8

04050-13018

PIN,COTTER

9

20B-54-12210

SPRING

10

01220-40408

SCREW

11

01641-20405

WASHER

11A

08037-01008

GROMMET

12

170-43-11370

GROMMET

13

207-46-11281

COVER

14

207-46-11321

GASKET

15

01010-51225

BOLT

16

01643-31232

WASHER

17

207-46-11181

COVER

18

207-46-11190

COVER

19

01010-51225

BOLT

20

01643-31232

WASHER

21

207-46-11361

PLATE

21

207-46-11360

PLATE

22

205-46-51240

CUSHION

23

205-46-51250

COLLAR

24

07000-03028

O-RING

25

01010-51665

BOLT

26

01643-31645

WASHER

27

207-46-12113

WEIGHT

28

207-46-12140

BOLT

29

207-46-12130

WASHER
