Запчасти Komatsu PC30-7 ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ

1

YMR000114

FILTER, ASSY.

2

YMR000007

VALVE, TAPER

3

YMR000008

SPRING

4

YMR000115

ELEMENT, ASSY.

6

YMR000116

LINK

7

YMR000117

CUP, STRAINER

8

YMR000118

RING, NUT

9

YMR000119

SPRING

10

YMR000010

SCREW

11

YMR000383

O-RING

12

YMR000385

O-RING

13

YMR000386

O-RING

14

YMR000077

CLAMP

15

YMR000200

CAP

16

YMR000392

BOLT

17

YMR000005

SCREW

18

YMR000001

JOINT

19

YMR000093

CLAMP

20

YMR000011

GASKET

21

YMR000032

PIPE

22

YMR000093

CLAMP

23

YMR000093

CLAMP

24

YMR000077

CLAMP

25

YMR000061

PIPE

26

YMR000048

PIPE

27

YMR000049

UNION

28

YMR000200

CAP

29

YMR000276

PIPE

30

YMR000121

VALVE

38

YMR000375

GASKET

39

YMR000280

WATER SEPARATOR

41

YMR000007

VALVE, TAPER

42

YMR000008

SPRING

43

YMR000009

HANDLE, COCK

44

YMR000076

BOWL, FUEL STRAINER

45

YMR000003

O-RING

46

YMR000012

RING, NUT

47

YMR000062

SPRING

48

YMR000063

FLOAT

49

YMR000002

PLUG

50

YMR000010

SCREW

51

YMR000341

SCREEN

52

YMR000376

GASKET

53

YMR000385

O-RING

54

YMR000276

PIPE

55

YMR000392

BOLT

56

YMR001073

BRACKET

57

YMR000093

CLAMP

58

YMR001074

PIPE
