Запчасти Komatsu PC30-7 ГИДР. НАСОС. (/)(№-) ГИДРАВЛИКА

Схема запчастей Komatsu PC30-7 - ГИДР. НАСОС. (/)(№-) ГИДРАВЛИКА
1
2
3
3
4
5
5
5
6
6
6
7
8
9
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
27
28
29
30
31
32
33

Артикул

Название

Примечание

Количество

|$0

20S-60-74410

HYDRAULIC PUMP ASS'Y

|$3

UC4100415937

COVER ASS'Y

1

COVER

2

UC1100463892

PLATE,CONTROL

3

PIN

4

01252-31030

BOLT

5

UC1701538797

PLUG

6

UC1100232432

ORIFICE

7

BEARING

8

UC1198273502

PLUG

9

07000-11008

O-RING

10

UC1100365826

PACKING

11

UC1100127413

COUPLING

12

UC1100127468

RING,SNAP

13

01252-31050

BOLT

|$17

UC4100464278

SPRING ASS'Y

14

UC1100366067

SEAT,SPRING

15

UC1100364731

SEAT,SPRING

16

UC1100365037

COVER

17

UC1100330307

SCREW,ADJUSTER

18

UC1100463939

SPRING

19

UC1100379036

SPRING

20

07000-13030

O-RING

21

01252-30830

BOLT

22

UC1301987009

NUT

23

UC1100365752

SHIM,0.3MM

23

UC1100365761

SHIM,0.5MM

23

UC1100365779

SHIM,1.0MM

|$30

UC4100415946

CYLINDER ASS'Y

24

UC1100392809

CYLINDER

25

UC1100379009

PISTON

26

UC1100365725

PIN

27

UC1100392819

PIN

28

01252-30825

BOLT

29

UC1300042004

O-RING

30

UC1300014009

O-RING

31

UC1300034003

O-RING

32

UC1100365835

SPRING

33

UC1100365954

SEAT,SPRING

Выбрано товаров: 39
