Запчасти Komatsu PC290NLC-8K ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН, ДЛЯ MACHINE С -ДОПОЛН. АКТУАТОР КОНТУР (/) H ГИДРАВЛИКА

|1

723-48-23902

Valve Assembly

|1

723-48-23900

Valve Assembly

|1

723-40-72100

Valve Assembly

1

Body

2

Spool

3

723-40-72800

Plate Assembly

4

702-21-57400

Pilot Valve

5

723-46-15111

Case

6

07430-71380

O-Ring

7

723-40-71330

Retainer

8

723-40-71340

Spring

9

723-40-71350

Retainer

10

01252-60816

Bolt

11

723-40-71870

Union

12

02896-11008

O-Ring

13

07002-11423

O-Ring

14

07040-11409

Plug

15

07002-11423

O-Ring

16

01252-60855

Bolt

17

01252-60635

Bolt

18

Spool Assembly

19

723-40-71850

Spring

20

723-46-18720

O-Ring

21

Spool

22

723-40-71390

Spring

23

723-46-18720

O-Ring

|24

723-40-71900

Valve Assembly

24

723-40-91600

Valve Assembly, Relief

25

702-16-53920

O-Ring

26

07002-11623

O-Ring

27

Block

28

Spool

29

Spring

30

702-21-55620

Plug

31

07002-11423

O-Ring

32

702-21-55710

Seat

33

702-21-55720

Spring

34

04260-00793

Ball

35

07000-11009

O-Ring

36

Plug
