Запчасти Komatsu PC290NLC-8K ОСНОВН. НАСОС (7/) Y FIELD REPВОЗД. ЗАПЧАСТИ ДЛЯ ОБСЛУЖ-Я

|1

708-2L-00790

Pump Assembly

|1

708-2L-00600

Pump Assembly

|1

708-2L-01600

Pump Sub-Assembly

1

708-2L-32170

Shaft, Rear

2

708-2L-32150

Bearing

3

708-2E-05040

Washer Kit

|3

Washer T= 3.1MM

|3

Washer T= 3.0MM

|3

Washer T= 2.9MM

|3

Washer T= 2.8MM

4

708-25-12790

Ring, Snap

|5

708-2L-06480

Block Assembly, Rear

5

Block, Cylinder

6

Plate, Valve

7

720-68-19610

Pin

8

04065-04818

Ring, Snap

9

708-2L-23131

Seat

10

708-2L-33160

Spring

11

708-7L-13140

Seat

12

708-2L-23351

Guide, Retainer

13

708-2L-23360

Pin

14

708-2L-33350

Retainer, Shoe

15

708-2L-33430

Piston Sub-Assembly

|16

708-2L-06630

Cradle Assembly

16

Cradle

17

Cam, Rocker

18

04020-01228

Pin, Dowel

19

01252-61230

Bolt
