Запчасти Komatsu PC290NLC-8K ОСНОВН. НАСОС (/) Y FIELD REPВОЗД. ЗАПЧАСТИ ДЛЯ ОБСЛУЖ-Я

|1

708-2L-00790

Pump Assembly

|1

708-2L-00600

Pump Assembly

|1

708-2L-01600

Pumb Sub-Assembly

1

708-2L-32160

Shaft, Front

2

708-2L-32150

Bearing

3

708-2E-05040

Washer Kit

|3

Washer T= 3.1MM

|3

Washer T= 3.0MM

|3

Washer T= 2.9MM

|3

Washer T= 2.8MM

4

708-25-12790

Ring, Snap

5

708-25-52861

Seal, Oil

6

708-2L-22160

Spacer

7

04065-06825

Ring

|8

708-2L-06470

Block Assembly, Front

8

Blcok, Cylinder

9

Plate, Valve

10

720-68-19610

Pin

11

04065-04818

Ring, Snap

12

708-2L-23131

Seat

13

708-2L-33160

Spring

14

708-7L-13140

Seat

15

708-2L-23351

Guide, Retainer

16

708-2L-23360

Pin

17

708-2L-33350

Retainer, Shoe

18

708-2L-33430

Piston Sub-Assembly

|19

708-2L-06630

Cradle Assembly

19

Cradle

20

Cam, Rocker

21

04020-01228

Pin, Dowel

22

01252-61230

Bolt
