Запчасти Komatsu PC290NLC-8K РУКОЯТЬ (.M) (№K-) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

206-70-K2381

Arm Assembly

1

206-70-K8021

Arm

2

20Y-70-22B81

Plate (Welded)

3

20Y-70-22F80

Bar (Welded)

4

20Y-70-22F90

Bar (Welded)

5

20Y-70-42E51

Plate (Welded)

6

20Y-970-3570

Bracket (Welded)

7

20J-70-12180

Seat (Welded)

8

206-62-K2740

Bracket (Welded)

9

20Y-62-K7290

Seat (Welded)

10

20Y-70-31272

Bushing

11

20Y-70-32410

Bushing

12

21K-70-12161

Bushing

13

07145-00090

Seal

14

20Y-70-23230

Seal

15

206-70-71340

Pin

16

206-70-K4570

Plate

|16

20Y-62-K7650

Plate

17

01010-81240

Bolt

|17

01010-81230

Bolt

18

01643-31232

Washer

19

20Y-70-31431

Spacer, 1.0mm

20

206-70-71350

Pin

21

205-70-66581

Plate

|21

205-70-66580

Plate

22

01010-81230

Bolt

23

01643-31232

Washer

24

20Y-70-31431

Spacer, 1.0mm

25

206-70-71451

Spacer, 2.0mm

26

707-H1-X0120

Cylinder Group

|26

707-F1-X0120

Cylinder Group

|26

707-01-XR930

Cylinder Group

|26

707-01-XJ930

Cylinder Group
