Запчасти Komatsu PC290NLC-8K ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) (ДЛЯ .M РУКОЯТЬ) (LC DEMO) (№K77-) T РАБОЧЕЕ ОБОРУДОВАНИЕ

G-1

707-H1-X0120

Cylinder Group

|1

707-F1-00120

Cylinder Assembly

1

707-13-14870

Cylinder

2

707-76-80431

Bushing

3

07145-00080

Seal, Dust (Kit : C05)

4

721-58-10380

Rod, Piston

5

707-76-80020

Bushing

6

20Y-70-23230

Seal (Kit : C05)

7

707-27-14690

Cylinder Head

8

07179-13114

Ring, Snap

9

707-56-10740

Seal, Dust (Kit : C05)

10

707-52-90780

Bushing

11

707-75-10160

Ring, Snap

12

707-51-10030

Packing (Kit : C05)

13

07000-15130

O-Ring (Kit : C05)

14

707-35-91420

Ring, Back-Up (Kit : C05)

15

707-51-10650

Ring

16

01010-81875

Bolt

17

707-41-11840

Washer

18

707-36-14650

Piston

19

707-44-14150

Ring, Piston (Kit : C05)

20

707-39-14110

Ring, Wear (Kit : C05)

21

707-44-14910

Ring

22

07001-05090

Ring, Back-Up (Kit : C05)

23

07000-15090

O-Ring (Kit : C05)

24

01310-01216

Screw

25

07020-00000

Fitting, Grease

26

707-86-67960

Tube

27

07372-21060

Bolt

28

01643-51032

Washer

29

07372-21045

Bolt

30

01643-51032

Washer

31

07000-13030

O-Ring (Kit : C05)

32

707-88-22680

Bracket

33

707-88-21361

Band

34

07372-21035

Bolt

35

01643-51032

Washer

36

07238-32738

Clip

37

01597-01009

Nut

38

01643-31032

Washer

39

707-88-33030

Cap

40

07371-30640

Flange, Split

41

07372-21035

Bolt

42

01643-51032

Washer

|$47

707-99-59120

Service Kit
