Запчасти Komatsu PC290NLC-8K РУКОЯТЬ (/) (.M) (№K~K77) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

707-01-XR920

Cylinder Assembly

1

707-13-13930

Cylinder

2

707-76-80431

Bushing

3

07145-00080

Seal, Dust, (Kit : C04)

4

707-58-90E70

Rod, Piston

5

707-76-80020

Bushing

6

20Y-70-23230

Seal, (Kit : C04)

7

707-27-13750

Cylinder Head

8

07179-13104

Ring, Snap

9

195-63-94170

Seal, Dust, (Kit : C04)

10

707-52-90680

Bushing

11

707-75-90110

Ring, Snap

12

707-51-90030

Packing, (Kit : C04)

13

07000-15120

O-Ring, (Kit : C04)

14

707-35-91320

Ring, Back-Up, (Kit : C04)

15

707-51-90650

Ring, (Kit : C04)

16

01010-81875

Bolt

17

707-41-11840

Washer

18

707-36-13780

Piston

19

707-44-13150

Ring, Piston, (Kit : C04)

20

707-39-13150

Ring, Wear, (Kit : C04)

21

707-44-13911

Ring

22

707-35-90940

Ring, Back-Up, (Kit : C04)

23

07000-15080

O-Ring, (Kit : C04)

24

01310-01216

Screw

25

07020-00000

Fitting, Grease

26

707-86-67930

Tube

27

07372-21060

Bolt

28

01643-51032

Washer

29

07372-21045

Bolt

30

01643-51032

Washer

31

07000-13030

O-Ring, (Kit : C04)

32

707-88-22640

Bracket

33

707-88-21331

Band

34

07372-21035

Bolt

35

01643-51032

Washer

36

07283-32738

Clip

37

01597-01009

Nut

38

01643-31032

Washer

39

707-88-33030

Cap

40

07371-30640

Flange, Split

41

07372-21035

Bolt

42

01643-51032

Washer
