Запчасти Komatsu PC290NLC-8K СОЛЕНОИДНЫЙ КЛАПАН КОНТУР, ДЛЯ MACHINE С -ДОПОЛН. АКТУАТОР КОНТУР (/) H ГИДРАВЛИКА

1

208-62-72310

Hose, L=950mm

2

20Y-62-22790

Band, Red

3

20Y-62-22810

Band, Yellow

4

20Y-62-51930

Hose, L=650mm

5

20Y-62-51940

Hose, L=1350mm

6

20Y-62-58540

Hose, L=550mm

|6

20Y-62-51993

Hose, L=600mm

7

206-62-26180

Hose, L=400mm

8

20Y-62-51260

Hose, L=1200mm

9

20Y-62-22860

Band, Brown

10

20Y-62-51960

Hose, L=700mm

11

20Y-62-22810

Band, Yellow

12

20Y-62-52121

Hose, L=1800mm

13

206-62-26190

Hose, L=1080mm

14

01010-81085

Bolt

15

01643-31032

Washer

16

08034-20536

Band

17

04434-51010

Clip

18

01010-81020

Bolt

19

01643-31032

Washer

20

04434-51512

Clip

21

01010-81225

Bolt

22

01643-31232

Washer

23

20Y-62-22820

Band, Blue

24

02760-00219

Hose

25

02760-00218

Hose

26

20Y-62-51930

Hose, L=650mm

27

04434-51212

Clip

28

01010-81225

Bolt

29

01643-31232

Washer

30

04434-52512

Clip

|30

04434-52212

Clip

31

04434-51012

Clip
