Запчасти Komatsu PC290NLC-7K КЛАПАН ПЕРЕГРУЗКИ (ДЛЯ ЦИЛИНДРА СТРЕЛЫ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

702-21-08330

PILOT VALVE

1

BODY,VALVE

2

SPOOL

3

702-21-38510

CASE

4

702-21-38420

RETAINER¤ 2.0MM

|4

702-21-38550

RETAINER¤ 1.7MM

|4

702-21-38560

RETAINER¤ 2.3MM

|4

702-21-38610

RETAINER¤ 1.8MM

|4

702-21-38620

RETAINER¤ 1.9MM

|4

702-21-38630

RETAINER¤ 2.1MM

|4

702-21-38640

RETAINER¤ 2.2MM

5

702-21-38430

FLANGE

6

702-21-38440

SPRING

7

702-21-38650

SPRING

8

702-21-38460

O-RING

9

702-21-38470

O-RING

10

702-21-38480

PLUG

11

01252-60825

BOLT

12

01252-60835

BOLT

13

01252-60620

BOLT

14

01641-20608

WASHER

15

07000-12021

O-RING

16

709-74-92810

VALVE

17

709-75-92220

SPRING

18

700-93-11320

O-RING

19

700-93-11330

RING,BACK-UP

|20

723-40-91500

VALVE ASS'Y,RELIEF

20

SLEEVE

21

700-80-64220

RING

22

700-22-11410

O-RING

23

SEAL

24

POPPET

25

PISTON

26

SEAT

27

SPRING

28

SEAL

29

709-25-11390

O-RING

30

POPPET

31

O-RING

32

PLUG

33

NUT

34

SPRING

35

O-RING

36

SPACER

37

NUT
