Запчасти Komatsu PC290NLC-7K НАСОС АВТОМАТИЧ. ЗАПРАВКИ ТОПЛИВА РАЗНОЕ

1

195-33-11220

SPACER

2

01010-81250

BOLT

3

01643-31232

WASHER

4

04434-51012

CLIP

5

01010-81225

BOLT

6

01643-31232

WASHER

7

08034-00519

BAND

8

04434-51012

CLIP

9

195-33-11220

SPACER

10

01010-81250

BOLT

11

01643-31232

WASHER

12

206-04-K1130

HOSE

|12

206-04-71121

HOSE

|12

206-04-71120

HOSE

13

07281-00419

CLAMP

14

206-04-71130

TUBE

15

04434-52512

CLIP

16

01010-81225

BOLT

17

01643-31232

WASHER

18

04434-52512

CLIP

19

198-43-15310

COLLAR¤ 10MM

20

01010-81235

BOLT

21

01643-31232

WASHER

22

206-04-K1120

HOSE

|22

206-04-71141

HOSE

|22

206-04-71140

HOSE

23

07281-00419

CLAMP

24

581-04-22290

CLIP

25

01010-81225

BOLT

26

01643-31232

WASHER

27

205-62-53780

COVER

28

08034-00834

BAND

29

20Y-04-K2350

HOSE

|29

207-04-71511

HOSE

|29

207-04-71510

HOSE

30

07281-00419

CLAMP

31

20Y-04-K1570

VALVE ASS'Y

|31

207-04-K1160

VALVE ASS'Y,FOOT

32

20Y-04-38170

BRACKET

33

01010-81225

BOLT

34

01643-31232

WASHER

35

206-04-K1110

PUMP ASS'Y,(SEE FIG.Y1040-01A0)
