Запчасти Komatsu PC290NLC-6K СЕРДЦЕВИНА БЛОК В СБОРЕ (С КОНДИЦИОНЕРОМ)(№K-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20Y-979-3712

UNIT ASS'Y

|1

ND445800-9056

.CORE UNIT ASS'Y

1

ND245420-4095

..CASE

2

ND447600-0651

..EVAPORATOR

|2

ND949142-0030

...O-RING

3

ND077500-0710

..THERMISTOR

4

ND246690-2840

..CLAMP

5

ND447500-1390

.VALVE

6

ND446870-1990

.TUBE

|6

ND949142-0030

...O-RING

|6

ND949142-0010

...O-RING

7

ND949046-2150

..BOLT

8

ND146984-5680

..GROMMET

9

ND116730-0490

..DOOR ASS'Y

10

ND116730-0500

..DOOR ASS'Y

11

ND245420-6002

..CASE ASS'Y

12

ND116452-6061

..CASE

13

ND949001-1730

..SCREW

14

ND116420-2782

..CORE ASS'Y

15

ND116427-5920

..PIPE

16

195-979-4841

..HOSE

17

ND113600-9301

..VALVE ASS'Y

18

ND017265-5480

..HOSE

19

ND116427-5930

..PIPE

20

ND246780-4220

..CLAMP

21

ND246780-4000

..CLAMP

22

ND949001-2690

..SCREW

23

ND017732-3041

..LEVER

24

ND91370-03081

..SCREW

25

ND017732-3060

..LEVER

26

ND017732-4600

..LEVER

27

17M-911-3330

..BUSHING

28

17M-911-3290

..CLAMP

29

ND116662-3780

..SHAFT

30

ND063700-6390

..SERVO MOTOR ASS'Y

31

195-Z11-6280

..BUSHING

32

ND90930-05201

..SCREW

33

ND146668-4880

..PACKING

34

ND056800-3130

..RELAY ASS'Y

35

ND017660-3490

..BRACKET

36

ND146525-3990

..BRACKET

37

ND90930-05121

..SCREW

38

ND146525-4000

..BRACKET

39

ND90930-06141

..SCREW

40

ND949351-0860

..CLIP

41

ND443440-0030

..SWITCH

|41

ND949142-0160

...O-RING

|41

ND949142-0040

...O-RING

42

ND146668-2030

..PACKING

43

ND146691-2790

..CLAMP
