Запчасти Komatsu PC290NLC-6K МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-75-01230

SWING MOTOR ASS'Y

|1

706-75-03350

MOTOR SUB ASS'Y

1

565-14-22440

O-RING

2

01252-61445

BOLT

3

706-75-43660

SHAFT,DRIVE

4

706-75-42880

BEARING

5

706-75-43810

SPACER

6

706-7E-11260

SPRING

7

706-7E-11270

SEAT

8

706-76-40890

BEARING

9

706-75-05040

SPACER KIT

|9

SPACER¤ 3.1MM

|9

SPACER¤ 3.4MM

|9

SPACER¤ 3.7MM

10

04064-04518

RING,SNAP

11

706-7E-11280

SEAL,OIL

12

706-75-43720

SPACER

13

04065-06220

RING

14

706-75-43190

BLOCK,CYLINDER

15

706-75-43741

PLATE,VALVE

16

706-75-43750

PIN,DOWEL

17

706-75-43120

SHAFT,CENTER

18

706-75-43130

RING,CENTER

19

706-75-43140

SPRING

|20

706-75-05020

RETAINER KIT

20

RETAINER

21

SCREW

22

706-75-43160

PISTON SUB ASS'Y

23

706-75-92130

PLATE

24

706-75-92340

PLATE

25

706-75-92350

DISK

26

706-75-92380

PISTON,BRAKE

27

706-75-92390

RING,BRAKE

28

07000-12145

O-RING

29

706-75-92310

O-RING

30

706-75-92370

SPRING
