Запчасти Komatsu PC290NLC-6K ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

206-63-K1610

CYLINDER ASS'Y

1

206-63-K1620

CYLINDER

2

707-76-10130

BUSHING

3

07145-00100

SEAL,DUST

4

206-63-K1630

ROD,PISTON

5

206-63-K1670

BUSHING

6

07145-00080

SEAL

7

707-27-16920

HEAD,CYLINDER

8

07179-13126

RING,SNAP

9

198-63-94170

SEAL,DUST

10

707-52-90850

BUSHING

11

707-51-11030

PACKING,ROD

12

07000-15150

O-RING

13

707-35-91640

RING,BACK-UP

14

707-51-11630

RING,BUFFER

15

01010-62085

BOLT

16

707-88-75310

WASHER

17

206-63-K1650

PISTON

18

707-44-15180

RING,PISTON

19

707-39-15820

RING,WEAR

20

707-44-15911

RING

21

707-71-61111

PLUNGER

22

707-71-60250

PLUNGER

23

07020-00900

FITTING,GREASE

24

206-63-K1660

COLLAR

25

707-35-91640

RING,BACK-UP

26

07000-15150

O-RING

27

07001-05100

RING

28

07000-15100

O-RING

29

01310-01216

SCREW

30

04260-00635

BALL

31

707-71-91270

CAP

32

206-63-K1580

TUBE

33

07000-13030

O-RING

34

01435-01055

BOLT

35

01435-01040

BOLT

36

01010-81080

BOLT

37

01643-31032

WASHER

38

707-88-11560

PLATE

39

20D-62-17860

ELBOW

40

07000-13035

O-RING

41

07283-22738

CLIP

42

01599-01011

NUT

43

01643-31032

WASHER

44

206-63-K1680

BRACKET

45

206-63-K1690

BAND

46

01010-81240

BOLT

47

01643-51232

WASHER
