Запчасти Komatsu PC290NLC-6K ЦИЛИНДР СТРЕЛЫ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

206-63-K1721

CYLINDER ASS'Y

1

206-63-K1730

CYLINDER

2

206-63-K1190

BUSHING

3

07145-00080

SEAL,DUST

4

206-63-K1740

ROD,PISTON

5

707-76-80220

BUSHING

6

07145-00080

SEAL

7

707-27-14920

HEAD,CYLINDER

8

07179-13114

RING,SNAP

9

176-63-56170

SEAL,DUST

10

707-52-90780

BUSHING

11

707-51-10030

PACKING,ROD

12

07000-15130

O-RING

13

707-35-91420

RING,BACK-UP

14

707-51-10630

RING,BUFFER

15

01010-61875

BOLT

16

707-41-11840

WASHER

17

707-36-14410

PISTON

18

707-44-14180

RING,PISTON

19

707-39-14820

RING,WEAR

20

707-44-14910

RING

21

707-71-61050

PLUNGER

22

707-71-32890

COLLAR

23

707-35-91420

RING,BACK-UP

24

07000-15130

O-RING

25

07001-05090

RING

26

07000-15090

O-RING

27

01310-01216

SCREW

28

206-63-K1850

TUBE,L.H.

|28

206-63-K1840

TUBE,R.H.

29

07000-13030

O-RING

30

01435-01055

BOLT

31

01435-01040

BOLT

32

07283-22738

CLIP

33

01599-01011

NUT

34

01643-31032

WASHER

35

206-63-K1820

BRACKET,L.H.

|35

206-63-K1810

BRACKET,R.H.

36

206-63-K1830

BAND

37

01010-81035

BOLT

38

01643-51032

WASHER
