Запчасти Komatsu PC290NLC-10 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, ВНУТР. ЧАСТИ, МОТОР ХОДА (/) МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

207-27-00471

Final Drive Assembly

|$1

708-8H-00351

Motor Assembly

1

708-8H-32120

Shaft

2

708-8H-32150

Bearing

3

708-8H-32170

Bearing

4

708-8H-05050

Spacer Kit

5

708-1F-12281

Seal, Oil

6

708-8H-32160

Spacer

7

04065-07825

Ring, Snap

|$16

708-8H-04810

Cylinder Block Assembly

10

708-18-13230

Pin

11

708-8H-33360

Pin

12

708-8H-33141

Spacer

13

708-8H-33750

Spring

14

04065-06020

Ring, Snap

15

708-8H-33512

Retainer

16

708-8H-33340

Retainer

17

708-8H-33650

Piston Subassembly

18

708-8H-33482

Cam, Rocker

19

04260-02857

Ball

20

708-8H-34310

Piston

21

708-8H-34290

Spring

22

708-8H-34151

Spring

23

708-8K-14210

Plug

24

07002-13334

O-Ring

25

708-8H-35130

Plate

26

708-8H-35180

Disc

27

708-8H-35141

Piston, Brake

28

07000-15175

O-Ring

29

07001-05175

Ring, Back-Up

30

07000-15195

O-Ring

31

07001-05195

Ring, Back-Up

32

708-8H-35150

Spring
