Запчасти Komatsu PC290NLC-10 ЦИЛИНДР РУКОЯТИ ЦИЛИНДР РУКОЯТИ

Схема запчастей Komatsu PC290NLC-10 - ЦИЛИНДР РУКОЯТИ ЦИЛИНДР РУКОЯТИ
40
42
23
53
53
54
58
57
54
55
56
52
54
5
36
34
33
4
6
6
9
30
50
51
29
28
4
52
51
50
49
53
46
45
44
47
43
41
39
38
37
14
13
10
9
8
7
12
32
30
31
11
29
28
27
26
25
24
19
20
21
18
22
16
17
15
2
35
3
1
48

Артикул

Название

Примечание

Количество

|$1

707-E1-00400

Cylinder Assembly

1

707-13-15540

Cylinder

2

707-58-11740

Rod, Piston

3

707-76-10290

Bushing

4

07145-00100

Seal, Dust, (Kit : K03)

5

707-76-80431

Bushing

6

07145-00080

Seal, Dust, (Kit : K03)

7

07020-00000

Fitting, Grease

8

707-71-35170

Collar

9

707-35-31410

Ring, Back-Up, (Kit : K03)

10

07000-B5140

O-Ring, (Kit : K03)

11

707-71-61140

Plunger

12

707-71-80280

Plunger

13

04260-00635

Ball, Steel

14

707-71-91270

Cap

15

707-27-15620

Head, Cylinder

16

707-56-11740

Seal, Dust, (Kit : K03)

17

07179-13126

Ring, Snap

18

707-51-11860

Packing, Rod, (Kit : K03)

19

707-51-11650

Ring, Buffer, (Kit : K03)

20

707-35-31410

Ring, Back-Up, (Kit : K03)

21

07000-B5140

O-Ring, (Kit : K03)

22

707-52-90851

Bushing

23

707-75-11040

Ring, Snap

24

01010-82085

Bolt

25

707-88-75310

Washer

26

707-36-15260

Piston

27

707-44-15150

Ring, Piston, (Kit : K03)

28

707-39-15110

Ring, Wear, (Kit : K03)

29

707-44-15911

Ring

30

707-35-31000

Ring, Back-Up, (Kit : K03)

31

07000-B5100

O-Ring, (Kit : K03)

32

01310-01216

Screw

33

707-83-13010

Valve

34

07750-01628

Spring

35

707-87-14070

Plug

36

07002-12034

O-Ring, (Kit : K03)

37

707-86-67920

Tube

38

20D-62-17860

Elbow

39

07372-21060

Bolt

40

01643-51032

Washer

41

07372-21045

Bolt

42

01643-51032

Washer

43

07000-13030

O-Ring, (Kit : K03)

44

07000-13035

O-Ring, (Kit : K03)

45

707-88-22670

Bracket

46

707-88-21351

Band

47

01010-81080

Bolt

48

01643-31032

Washer

49

707-88-36130

Plate

50

01643-31032

Washer

51

01597-01009

Nut

52

07283-32738

Clip, Pipe

53

07372-21035

Bolt

54

01643-51032

Washer

55

707-88-33030

Cap

56

07371-30640

Flange, Split

57

707-88-33040

Cap

58

07371-31049

Flange, Split

K03

707-99-59680

Seal Kit, Hydraulic Cylinder

Выбрано товаров: 60
