Запчасти Komatsu PC290LC ОСНОВ. СТРЕЛА (QC) ТРУБЫ (SHT /) T РАБОЧЕЕ ОБОРУДОВАНИЕ

1

206-62-KB330

TUBE

2

206-62-KB262

TUBE

|2

206-62-KB261

TUBE

3

KV-X5X0-6120

FLANGE

4

01252-71025

BOLT

5

07000-13032

O-RING

6

07000-13025

O-RING

7

07371-30640

FLANGE

8

07372-21035

BOLT

9

01643-51032

WASHER

10

206-62-KB340

TUBE

11

206-62-KB311

TUBE

|11

206-62-KB310

TUBE

12

07000-13025

O-RING

13

07371-30640

FLANGE

14

07372-21035

BOLT

15

01643-51032

WASHER

16

206-62-KB251

TUBE

|16

206-62-KB250

TUBE

17

206-62-KB850

TUBE

18

206-62-KB841

TUBE

|18

206-62-KB840

TUBE

19

07000-13025

O-RING

20

07371-30640

FLANGE

21

07372-21035

BOLT

22

01643-51032

WASHER

23

206-62-KB241

TUBE

|23

206-62-KB240

TUBE

24

206-62-KB322

TUBE

24

206-62-KB321

TUBE

25

20Y-62-53240

BRACKET

26

01010-81645

BOLT

27

01643-31645

WASHER

28

206-62-KB272

TUBE

|28

206-62-KB271

TUBE

29

20Y-62-53230

BRACKET

30

01010-81645

BOLT

31

01643-31645

WASHER

32

206-62-KB281

TUBE

|32

206-62-KB280

TUBE

33

206-62-KB371

TUBE

34

02896-11015

O-RING

35

206-62-KB910

TUBE

36

02896-11008

O-RING

37

02777-00203

HOSE

38

02896-11008

O-RING

39

206-62-KB880

UNION

40

207-62-KB471

SEAL

41

21P-62-K3240

BAND (RED)

42

21P-62-K3250

BAND (YELLOW)

43

21P-62-K3260

BAND (BLUE)

44

21P-62-K3270

BAND (WHITE)

45

21P-62-K3280

BAND (BLACK)

46

21P-62-K3290

BAND (GREEN)

47

21P-62-K3310

BAND (BROWN)

48

21P-62-KH810

BAND (GREY)

49

207-70-KJ980

BRACKET

50

01010-81225

BOLT

51

01643-31232

WASHER
