Запчасти Komatsu PC290LC ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) (ДЛЯ .M РУКОЯТЬ) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

707-F1-00120

CYLINDER ASSEMBLY

1

707-13-14870

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL, DUST (KIT: C05)

4

721-58-10380

ROD, PISTON

5

707-76-80020

BUSHING

6

20Y-70-23230

SEAL (KIT: C05)

7

707-27-14690

CYLINDER HEAD

8

07179-13114

RING, SNAP

9

707-56-10740

SEAL, DUST (KIT: C05)

10

707-52-90780

BUSHING

11

707-75-10160

RING, SNAP

12

707-51-10030

PACKING (KIT: C05)

13

07000-15130

O-RING (KIT: C05)

14

707-35-91420

RING, BACK-UP (KIT: C05)

15

707-51-10650

RING

16

01010-81875

BOLT

17

707-41-11840

WASHER

18

707-36-14650

PISTON

19

707-44-14150

RING, PISTON (KIT: C05)

20

707-39-14110

RING, WEAR (KIT: C05)

21

707-44-14910

RING

22

07001-05090

RING, BACK-UP (KIT: C05)

23

07000-15090

O-RING (KIT: C05)

24

01310-01216

SCREW

25

07020-00000

FITTING, GREASE

26

707-86-67960

TUBE

27

07372-21060

BOLT

28

01643-51032

WASHER

29

07372-21045

BOLT

30

01643-51032

WASHER

31

07000-13030

O-RING (KIT: C05)

32

707-88-22680

BRACKET

33

707-88-21361

BAND

34

07372-21035

BOLT

35

01643-51032

WASHER

36

07238-32738

CLIP

37

01597-01009

NUT

38

01643-31032

WASHER

39

707-88-33030

CAP

40

07371-30640

FLANGE, SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER

|$45

707-99-59120

SERVICE KIT
