Запчасти Komatsu PC290LC-8K DIESEL ЧАСТЬICULATE ФИЛЬТР. И КРЕПЛЕНИЕ (№K-) B КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

20Y-01-K2231

Muffler Assembly

2

20Y-01-K2161

Hose

3

20Y-01-K2250

Ring

4

20Y-01-K2122

Pressure Sensor

5

20Y-01-K2111

Sensor

6

20Y-01-K2060

Mount

7

20Y-01-K1950

Flange

8

20Y-01-K1961

Tube

9

20Y-01-K1970

Clamp

10

20Y-01-K2071

Plate

|10

20Y-01-K2070

Plate

11

01224-40620

Screw

12

01643-30623

Washer

13

01580-10605

Nut

14

01435-01030

Bolt

15

20Y-01-K2081

Bracket

|15

20Y-01-K2080

Bracket

16

01435-01030

Bolt

17

01435-01035

Bolt

18

01643-31032

Washer

19

01580-11008

Nut

20

20Y-01-K2091

Bolt

|20

20Y-01-K2090

Bolt

21

01435-01030

Bolt

22

01435-01035

Bolt

23

01643-31032

Washer

24

01580-11008

Nut

25

6754-11-5420

Bracket

26

01435-01025

Bolt

27

01435-01035

Bolt

28

01643-31032

Washer

29

01580-01008

Nut

30

20Y-01-K2190

Tube

31

07260-20950

Hose

32

07285-00155

Clamp

33

20Y-01-K2291

Bracket

34

207-01-K1650

Water Seperator

35

01023-70410

Screw

36

207-01-K1090

Fitting

37

207-01-K1080

Fitting

38

01010-81225

Bolt

39

01643-31232

Washer

40

20Y-01-K2260

Filter Bag
