Запчасти Komatsu PC290LC-8K РУКОЯТЬ АВТОМАТИЧ. СМАЗ. ЧАСТИ (.M РУКОЯТЬ) (№K-) G АВТОМАТИЧ. СМАЗ. СИСТЕМА

1

20Y-62-K7560

Elbow

2

01010-81240

Bolt

3

01643-31232

Washer

4

206-70-K2580

Tube

5

206-70-K2590

Tube

6

20Y-62-K7560

Elbow

|7

206-70-K4742

Block Assembly

|7

206-70-K4741

Block Assembly

|7

206-70-K4740

Block Assembly

7

20Y-62-K7490

Block

8

206-70-K2530

Hose

9

206-70-K2561

Hose

|9

206-70-K2560

Hose

10

206-70-K2552

Hose

|10

206-70-K2551

Hose

|10

206-70-K2550

Hose

11

01252-70635

Bolt

12

20Y-62-K9420

Washer

13

20Y-62-K7560

Elbow

14

206-70-K4160

Bracket

15

04435-51210

Clip

16

01010-81020

Bolt

17

01643-31032

Washer

18

01010-81030

Bolt

19

01643-31032

Washer

20

206-70-K4130

Bracket

21

07283-33450

Clip

22

07283-53444

Seat

23

01597-01009

Nut

24

01643-31032

Washer

25

01010-81020

Bolt

26

01643-31032

Washer

27

04435-51210

Clip

28

20Y-62-K7340

Bracket

29

20J-70-12280

Clamp

30

01010-81016

Bolt

31

01643-31032

Washer

32

20Y-62-K7610

Clamp

33

20Y-62-K7620

Plate

34

20Y-62-K7570

Bolt

35

206-70-K2620

Tube

36

206-70-K2610

Tube

37

20Y-70-K5360

Bolt

38

20Y-62-K7320

Bracket

39

01010-81225

Bolt

40

01643-31232

Washer

41

08034-20414

Band

42

20Y-62-K8350

Hose

43

206-70-K2540

Hose

44

206-70-K2570

Hose

45

20Y-62-K7680

Fitting
