Запчасти Komatsu PC290LC-8K РУКОЯТЬ (.M) (№K-) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

206-70-K2264

Arm Assembly

1

206-970-K852

Arm

2

20Y-70-32E50

Seat (Welded)

3

20Y-970-3570

Bracket (Welded)

4

20J-70-12180

Seat (Welded)

5

206-62-K2740

Bracket (Welded)

6

20Y-62-K7290

Seat (Welded)

7

20Y-70-31272

Bushing

8

20Y-70-32410

Bushing

9

21K-70-12161

Bushing

12

07145-00090

Seal

13

20Y-70-23230

Seal

14

206-70-71340

Pin

15

206-70-K4570

Plate

|15

20Y-62-K7650

Plate

16

01010-81240

Bolt

|16

01010-81230

Bolt

17

01643-31232

Washer

18

20Y-70-31431

Spacer, 1.0mm

19

206-70-71350

Pin

20

205-70-66580

Plate

21

01010-81230

Bolt

22

01643-31232

Washer

23

20Y-70-31431

Spacer, 1.0mm

24

206-70-71451

Spacer, 2.0mm

25

707-G1-X0520

Cylinder Group

|25

707-E1-X0520

Cylinder Group

|25

707-01-XR920

Cylinder Group

|25

707-01-XJ920

Cylinder Group
