Запчасти Komatsu PC290LC-8K ЦИЛИНДР СТРЕЛЫ(/) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

707-01-0A390

Cylinder Assembly, LHS

1

707-13-14560

Cylinder

2

707-76-80431

Bushing

3

07145-00080

Seal, Dust

4

707-58-10690

Rod

5

707-76-80431

Bushing

6

07145-00080

Seal, Dust

7

707-27-14930

Head

8

07179-13114

Ring, Snap

9

176-63-56170

Seal, Dust

10

707-52-90780

Bushing

11

707-51-10030

Packing

12

07000-15130

O-Ring

13

707-35-91420

Ring, Back-Up

14

707-51-10640

Ring

15

01010-81875

Bolt

16

707-41-11840

Washer

17

707-36-14650

Piston

18

707-44-14180

Ring, Piston

19

707-39-14110

Ring, Wear

20

707-44-14910

Ring

21

707-71-71020

Plunger

22

07000-15090

O-Ring

23

07001-05090

Ring, Back-Up

24

01310-01216

Screw

25

707-71-34810

Collar

26

707-35-91420

Ring, Back-Up

27

07000-15130

O-Ring

28

707-86-66360

Tube, LHS

29

01435-01055

Bolt

30

01435-01040

Bolt

31

07000-13030

O-Ring

32

707-88-22650

Bracket, LHS

33

707-88-21341

Band

34

01435-01030

Bolt

35

07283-22738

Clip

36

01599-01011

Nut

37

01643-31032

Washer

38

707-88-33030

Cap

39

07371-30640

Flange, Split

40

07372-21035

Bolt

41

01643-31032

Washer
