Запчасти Komatsu PC290LC-8K МЕХАНИЗМ ПОВОРОТА (/) N ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|1

706-7G-01170

Motor Assembly

|1

706-7G-01041

Motor Assembly

|1

706-7G-01130

Motor Assembly

|1

702-75-01270

Valve Assembly

1

Sleeve

2

Seat, Valve

3

Valve

4

Piston

5

Spring

6

Rod

7

Screw

8

O-Ring

9

Ring, Back-Up

10

Nut

11

07000-F2020

O-Ring

12

07001-02020

Ring, Back-Up

13

07002-13034

O-Ring

|14

702-15-77000

Valve Assembly

14

Body

15

Spool

16

709-70-71610

Seal

17

702-15-71130

Spring

18

702-15-71140

Plug

19

07002-01423

O-Ring

20

07000-03042

O-Ring

21

07000-11009

O-Ring

22

01252-60825

Bolt
