Запчасти Komatsu PC290LC-8K МЕХАНИЗМ ПОВОРОТА (/) N ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|1

706-7G-01170

Motor Assembly

|1

706-7G-01041

Motor Assembly

|1

706-7G-01130

Motor Assembly

|1

706-7G-03090

Motor Subassembly

1

706-7G-41630

Shaft, Drive

2

706-75-42880

Bearing

3

706-7G-41660

Spacer

4

706-76-40890

Bearing

5

706-7G-41510

Spacer Kit

|5

Spacer, T=3.1mm

|5

Spacer, T=3.4mm

|5

Spacer, T=3.7mm

6

04064-04518

Ring, Snap, for Shaft Side

7

706-7E-11280

Seal, Oil

8

706-7G-41910

Spacer

9

04065-06220

Ring, Snap, for Hole Side

10

706-7G-41310

Block, Cylinder

11

706-7G-41720

Plate, Valve

12

706-75-43750

Pin, Dowel

13

706-7G-41320

Shaft, Center

14

706-7G-41130

Ring, Center

15

706-7G-41140

Spring

|15

706-7G-05010

Retainer Kit

16

Retainer

17

Screw

18

706-7G-41410

Piston Subassembly

19

706-7G-91441

Plate

20

706-7G-91450

Disc

21

706-7G-91120

Piston, Brake

22

706-75-92310

O-Ring

23

708-8F-31610

O-Ring

24

706-7G-91360

Spring
