Запчасти Komatsu PC290LC-8K КАБИНА (/) K OPERATORґS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|1

206-53-00410

Cab Assembly (ROPS)

|1

206-53-00112

Cab Assembly

|1

206-53-00080

Cab Assembly

|1

20Y-53-00091

Window Assembly

1

20Y-53-18511

Frame

2

20Y-53-11520

Glass

3

20Y-54-51531

Seal

4

20Y-53-11551

Seal

5

22B-54-15411

Lock Assembly

6

22B-54-15440

Case

7

22B-54-15470

Knob

8

22B-54-15421

Lock Assembly

9

22B-54-15450

Case

10

22B-54-15480

Knob

11

01435-40812

Bolt

12

20Y-54-52621

Roller

13

20Y-54-52681

Roller

14

20Y-53-12330

Pin

15

20Y-54-14590

Handle

16

01245-00616

Screw

17

01643-70623

Washer

18

20Y-53-12830

Bracket

19

01245-00816

Screw

20

01643-70823

Washer, Flat

21

20Y-54-51670

Stopper

22

20Y-54-51680

Stopper

23

01252-80616

Bolt

24

01643-70623

Washer

25

20Y-53-11561

Block Assembly

26

01245-00816

Screw

27

01643-70823

Washer, Flat

28

20Y-53-11661

Bracket

29

01245-00816

Screw

30

01643-70823

Washer, Flat

31

21J-06-12440

Switch

32

01583-11811

Nut

33

20Y-53-11581

Bracket

34

20Y-53-11641

Bracket

35

01435-00612

Bolt

36

20Y-54-11611

Stopper

37

01580-11008

Nut

38

20Y-54-51621

Striker

39

01584-31008

Nut, Flanged

40

01643-71032

Washer

41

20Y-53-11540

Seal

42

20Y-54-51420

Seal

43

20Y-53-12531

Cover

44

20Y-53-12310

Collar

45

01245-00616

Screw

46

01643-70623

Washer
