Запчасти Komatsu PC290LC-8K АКТУАТОР КОНТУР, ДОПОЛН. (/) H ГИДРАВЛИКА

1

01010-81040

Bolt

2

01643-31032

Washer

3

20Y-62-K6941

Bracket

|3

20Y-62-K6940

Bracket

4

07049-01215

Plug

5

07371-31049

Flange, Split

6

07372-21035

Bolt

7

01643-51032

Washer

8

07371-51260

Flange, Split

9

01010-81245

Bolt

10

01643-31232

Washer

11

20Y-62-43460

Nipple

12

02896-11008

O-Ring

13

07002-12034

O-Ring

14

11Y-62-12160

Elbow

15

02896-11008

O-Ring

16

07002-11423

O-Ring

|17

20Y-970-6450

Accumulator Assembly

17

Shell

|17

NFEB3401 A1

Bleeder Assembly

18

NFEB3026 A1

Bleeder

19

NFEB4475 Z0

Core

20

Nut

21

Cap

22

NFEB0427 Z0

Body Assembly

23

NFEB4477 Z0

Ring

24

O-Ring

25

Ring, Back-Up

26

Ring

27

Plate

28

205-970-5560

O-Ring

29

Bushing

30

20Y-62-43290

Elbow

31

07002-12434

O-Ring

32

20Y-62-43280

Bracket

33

01010-81295

Bolt

34

01643-31232

Washer

35

175-61-51750

Plate

36

01010-81225

Bolt

37

01643-31232

Washer

38

01010-81285

Bolt

39

01643-31232

Washer

40

07097-01005

Hose, Flange Type

41

07000-13032

O-Ring

42

07371-31049

Flange, Split

43

07372-21035

Bolt

44

01643-51032

Washer

45

07097-21218

Hose, Flange Type

46

07000-13038

O-Ring

47

07371-51260

Flange, Split

48

01010-81245

Bolt

49

01643-31232

Washer
