Запчасти Komatsu PC290LC-6K ПРЕДОТВРАЩ. СМЕЩЕНИЯ (РУКОЯТЬ) ГИДРАВЛИКА

1

206-63-K1590

TUBE

2

07372-21035

BOLT

3

01643-31032

WASHER

4

07000-13030

O-RING

5

702-21-08031

PILOT VALVE ASS'Y,(SEE FIG. Y1665-01A1)

6

07000-13030

O-RING

7

07372-21060

BOLT

8

07372-21055

BOLT

9

01643-31032

WASHER

10

07235-10311

ELBOW

11

07002-11423

O-RING

12

201-62-21650

ELBOW

13

20Y-62-K3940

SPACER

14

07002-12034

O-RING

15

07002-12034

O-RING

16

07040-11409

PLUG

17

07002-11423

O-RING

18

20Y-62-K3760

HOSE

19

08034-00519

BAND

20

20Y-62-19310

BRACKET

21

195-49-31470

CLIP

22

21T-68-11320

CLIP

23

01010-81230

BOLT

24

01643-31232

WASHER

25

04434-51512

CLIP

26

04434-52512

CLIP

27

01010-81260

BOLT

28

01643-31232

WASHER

29

120-54-42430

SPACER

30

04434-52512

CLIP

31

04434-51512

CLIP

32

04434-52512

CLIP

33

04434-51512

CLIP

34

20Y-62-K3730

TEE

35

07002-11423

O-RING

36

20E-60-K1250

POPPET

37

20Y-62-K3890

ELBOW

38

07002-11423

O-RING

39

07102-20576

HOSE

40

07236-10522

ELBOW

41

07002-12434

O-RING

42

07040-12412

PLUG

43

07002-12434

O-RING

44

07230-20210

UNION

45

07002-11423

O-RING
