Запчасти Komatsu PC290LC-6K ОСНОВН. КЛАПАН (-АКТУАТОР) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
№
Артикул
Название
Примечание
Количество
|1
723-48-14802
VALVE ASS'Y
|1
723-48-14801
VALVE ASS'Y
|1
723-40-66300
VALVE ASS'Y
1
CASE
2
SEAT
3
SEAT
4
BALL
5
PLUG
|6
709-70-74600
VALVE ASS'Y,SUCTION AND SAFETY
6
SLEEVE
7
SLEEVE
8
POPPET
9
PISTON
10
PLUG
11
POPPET
12
SCREW
13
SPRING
14
SPRING
15
SPRING
16
709-70-71610
SEAL
17
SEAL
18
O-RING
19
O-RING
20
O-RING
21
NUT
|22
709-70-74302
VALVE ASS'Y,SUCTION AND SAFETY
|22
709-70-74402
VALVE ASS'Y,SUCTION AND SAFETY
22
SLEEVE
23
SLEEVE
24
POPPET
25
PISTON
26
PLUG
27
POPPET
28
SCREW
29
SPRING
30
SPRING
31
SPRING
32
709-70-71610
SEAL
33
SEAL
34
O-RING
35
O-RING
|35
O-RING
36
O-RING
|36
O-RING
37
NUT
Выбрано товаров: 45
