Запчасти Komatsu PC290LC-6K ЦИЛИНДР КОВША ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

206-63-K1911

CYLINDER ASS'Y

1

206-63-K1921

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL,DUST

4

206-63-K1941

ROD,PISTON

5

707-76-80020

BUSHING

6

205-70-62140

SEAL,DUST

7

707-27-14920

HEAD,CYLINDER

8

07179-13114

RING,SNAP

9

176-63-56170

SEAL,DUST

10

707-52-90780

BUSHING

11

707-51-10030

PACKING,ROD

12

07000-15130

O-RING

13

707-35-91420

RING,BACK-UP

14

707-51-10630

RING,BUFFER

15

01010-61875

BOLT

16

707-41-11840

WASHER

17

707-36-14410

PISTON

18

707-44-14180

RING,PISTON

19

707-39-14820

RING,WEAR

20

707-44-14910

RING

21

07001-05090

RING,BACK-UP

22

07000-15090

O-RING

23

01310-01216

SCREW

24

206-63-K1931

TUBE

25

07000-13030

O-RING

26

01435-01055

BOLT

27

01435-01040

BOLT

28

707-88-13590

CLAMP

29

01010-81040

BOLT

30

01643-31032

WASHER

31

707-88-87100

BRACKET

32

707-88-87160

BAND

33

01010-81035

BOLT

34

01643-51032

WASHER

35

07020-00000

FITTING,GREASE

36

07020-00900

FITTING,GREASE
