Запчасти Komatsu PC290LC-10 C- ПОСЛЕОХЛАДИТЕЛЬ СИСТЕМА ОХЛАЖДЕНИЯ

1

206-03-35181

SHROUD

2

01010-81030

BOLT

3

01643-31032

WASHER

|$3

206-03-35310

COVER ASSEMBLY

4

NSS

COVER

5

206-03-35330

SHEET

6

01010-81030

BOLT

7

01643-31032

WASHER

|$8

206-03-31421

BRACKET ASSEMBLY

8

NSS

BRACKET

9

2A5-03-11711

SHEET

10

01010-81030

BOLT

11

01643-31032

WASHER

|$13

206-03-35480

COVER ASSEMBLY

12

206-03-31450

SHEET

13

NSS

COVER

14

206-03-35470

SHEET

15

01010-81020

BOLT

16

01643-31032

WASHER

17

206-03-35141

AFTERCOOLER

18

01010-81040

BOLT

19

01643-31032

WASHER

20

208-03-41580

COLLAR

21

208-03-41590

CUSHION

22

6110-23-6490

SPACER

23

206-03-31261

BRACKET

24

01010-81020

BOLT

25

01643-31032

WASHER

26

206-03-31271

BRACKET

27

01010-81020

BOLT

28

01643-31032

WASHER

29

2A5-03-11381

HOSE

30

206-03-43340

CLIP

31

206-03-35410

SHEET

32

2A5-03-11481

SHEET

33

2A5-03-11490

SHEET

34

2A5-03-11531

SHEET

35

206-03-31480

SHEET

36

206-03-21690

SHEET

37

2A5-03-11561

SHEET

38

2A5-03-11521

SHEET

39

206-03-35420

SHEET

40

2A5-03-11991

SHEET

41

2A5-03-11571

SHEET

42

206-03-35271

COVER

43

01010-81020

BOLT

44

01643-31032

WASHER

45

20Y-03-41870

SEAL
