Запчасти Komatsu PC290LC-10 A8- ДВИГАТЕЛЬ REPВОЗД. ЗАПЧАСТИ ДЛЯ ОБСЛУЖ-Я ДВИГАТЕЛЬ

1

6736-29-1410

BUSHING, CAM. NO. 1

2

6736-29-1420

BUSHING, CAM. NO. 2. 3. 4. 5. 6. 7

|$2

6736-39-1130

SLEEVE, REAR

3

NSS

SLEEVE

4

NSS

SEAL

|$5

6754-29-8320

BEARING, T = 0.25 MM

5

NSS

BEARING, UPPER

6

NSS

BEARING, LOWER

|$8

6754-29-8310

BEARING, THRUST, T = 0.25 MM, OVERSIZED

7

NSS

BEARING, THRUST, UPPER

8

NSS

BEARING, LOWER

|$11

6754-28-8320

BEARING, T = 0.50 MM, UNDERSIZED

9

NSS

BEARING, UPPER

10

NSS

BEARING, T = 0.50 MM

|$14

6754-28-8310

BEARING, THRUST, T = 0.50 MM, OVERSIZED

11

NSS

BEARING, THRUST, UPPER

12

NSS

BEARING, T = 0.50 MM, LOWER

|$17

6754-27-8320

BEARING, T = 0.75 MM, UNDERSIZED

13

NSS

BEARING, UPPER

14

NSS

BEARING, LOWER

|$20

6754-27-8310

BEARING, THRUST, T = 0.75 MM, OVERSIZED

15

NSS

BEARING, THRUST, UPPER

16

NSS

BEARING, LOWER

|$23

6754-26-8320

BEARING, T = 1.00 MM, UNDERSIZED

17

NSS

BEARING, UPPER

18

NSS

BEARING, T = 1.00 MM, LOWER

|$26

6754-26-8310

BEARING, THRUST, T = 1.00 MM, OVERSIZED

19

NSS

BEARING, THRUST, UPPER

20

NSS

BEARING, T = 1.00 MM, LOWER

|$29

6754-28-8410

BEARING, THRUST, OVERSIZE (BORE/THRUST)

21

NSS

BEARING, THRUST, T = 0.50/0.50 MM, UPPER

22

NSS

BEARING, T = 0.50 MM, LOWER

23

NSS

BEARING, THRUST, T = 1.00/1.00 MM, UPPER

24

NSS

BEARING, T = 1.00 MM, LOWER

25

6738-39-3400

METAL, ROD, LOWER, UNDERSIZED, 0.25 MM

26

6738-38-3400

METAL, ROD, LOWER, UNDERSIZED, 0.50 MM

27

6738-37-3400

METAL, ROD, LOWER, UNDERSIZED, 0.75 MM

28

6738-36-3400

METAL, ROD, LOWER, UNDERSIZED, 1.00 MM

29

6755-39-2110

PISTON

|$39

6754-39-2010

RING ASSEMBLY, PISTON

30

NSS

RING, T = 0.05 MM, OVERSIZED

31

NSS

RING

32

NSS

RING, OIL

33

6754-32-3420

BEARING

34

6754-32-3430

BEARING

35

6754-32-3440

BEARING

36

6754-32-3450

BEARING
