Запчасти Komatsu PC290LC-10 AST- СТАРТЕР V - . KW ДВИГАТЕЛЬ

Схема запчастей Komatsu PC290LC-10 - AST- СТАРТЕР V - . KW ДВИГАТЕЛЬ
32
1
30
41
39
4
23
2
43
22
37
3
29
34
39
19
17
40
16
21
37
14
14
15
13
38
26
13
27
28
35
25
42
24
12
36
44
18
10
20
9
8
31
46
6
33
7
6
45
11
5

Артикул

Название

Примечание

Количество

|$0

600-863-5130

STARTING MOTOR ASSEMBLY

1

ND028100-5410

YOKE ASSEMBLY

2

ND028200-5250

ARMATURE ASSEMBLY

3

ND949100-3161

BEARING, BALL

N/I

ND949100-5290

BEARING, BALL

4

ND949100-3540

BEARING, BALL

|$6

ND028300-6551

CLUTCH SUBASSEMBLY

5

ND028099-3270

STARTING KIT, MOTOR

6

ND028300-6751

CLUTCH ASSEMBLY

7

ND949100-4500

BEARING, BALL

8

ND949100-1920

BEARING, BALL

9

ND949170-4040

SPRING

10

ND028381-0071

SHAFT

11

ND128401-5621

HOUSING

12

ND153400-9890

SWITCH ASSEMBLY

13

ND128099-5770

STARTING MOTOR KIT

14

ND028099-5100

STARTING MOTOR KIT

15

ND053660-0443

PLUNGER

16

ND053404-0240

GASKET

17

ND053505-0290

COVER

18

ND053480-7560

BOLT ASSEMBLY

19

ND949047-4440

BOLT

20

ND028065-0250

BUSHING

21

ND028510-0880

HOLDER ASSEMBLY, BRUSH

22

ND028520-0011

SPRING

23

ND128501-1090

FRAME

24

ND949120-0240

BALL

25

ND949170-4070

SPRING

26

ND028371-3210

PINION

27

ND028306-0070

ROLLER

28

ND028063-0030

RETAINER

29

ND028062-0130

COVER

30

ND949042-3680

BOLT

31

ND90801-10050

O-RING

32

ND949042-3690

BOLT

33

ND949006-4720

SCREW

34

ND949056-4480

NUT

35

ND028327-0171

RETAINER

36

ND90258-10001

WASHER

37

ND028901-0361

SEAL

38

ND028371-3200

PINION

39

ND949007-6530

SCREW

40

ND028530-1090

BRUSH ASSEMBLY

41

ND028530-1100

BRUSH ASSEMBLY

42

ND949007-6850

SCREW

43

ND028062-5790

COVER

44

ND90170-10061

NUT

45

ND028901-5190

SEAL

46

ND90200-06241

WASHER

Выбрано товаров: 49
