Запчасти Komatsu PC290LC-10 T- ЦИЛИНДР КОВША РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-E1-00230

CYLINDER, BUCKET ASSEMBLY

1

721-13-14030

CYLINDER

2

721-58-10100

ROD, PISTON

3

707-76-80431

BUSHING

4

07145-00080

SEAL, DUST

5

07020-00000

FITTING, GREASE

6

707-76-80020

BUSHING

7

20Y-70-23230

SEAL, DUST

8

07020-00000

FITTING, GREASE

9

707-27-14690

CYLINDER HEAD

10

707-56-10740

SEAL, DUST

11

07179-13114

RING, SNAP

12

707-52-90781

BUSHING

13

707-51-10860

PACKING, ROD

14

707-51-10650

RING, BUFFER

15

707-35-31310

RING, BACK-UP

16

07000-B5130

O-RING

17

01010-81875

BOLT

18

707-41-11840

WASHER

19

707-75-10160

RING, SNAP

20

707-36-14650

PISTON

21

707-44-14150

RING, PISTON

22

707-39-14110

RING, WEAR

23

707-35-30900

RING, BACK-UP

24

07000-B5090

O-RING

25

707-44-14910

RING

26

01310-01216

SCREW

27

707-86-67860

TUBE

28

07372-21060

BOLT

29

01643-51032

WASHER

30

07372-21045

BOLT

31

01643-51032

WASHER

32

07000-13030

O-RING

33

707-88-22680

BRACKET

34

707-88-21361

BAND

35

07372-21035

BOLT

36

01643-51032

WASHER

37

01643-31032

WASHER

38

01597-01009

NUT

39

07283-32738

CLIP, PIPE

40

707-88-33030

CAP

41

07371-30640

FLANGE, SPLIT

42

707-88-33040

CAP

43

07371-31049

FLANGE, SPLIT

|$44

707-99-59080

SERVICE KIT, BUCKET CYLINDER
