Запчасти Komatsu PC290LC-10 T- ЦИЛИНДР РУКОЯТИ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-E1-00400

CYLINDER, ARM ASSEMBLY

1

707-13-15540

CYLINDER

2

707-58-11740

ROD, PISTON

3

707-76-10290

BUSHING

4

07145-00100

SEAL, DUST

5

707-76-80431

BUSHING

6

07145-00080

SEAL, DUST

7

07020-00000

FITTING, GREASE

8

707-71-35170

COLLAR

9

707-35-31410

RING, BACK-UP

10

07000-B5140

O-RING

11

707-71-61140

PLUNGER

12

707-71-80280

PLUNGER

13

04260-00635

BALL, STEEL

14

707-71-91270

CAP

15

707-27-15620

HEAD, CYLINDER

16

707-56-11740

SEAL, DUST

17

07179-13126

RING, SNAP

18

707-51-11860

PACKING, ROD

19

707-51-11650

RING, BUFFER

20

707-35-31410

RING, BACK-UP

21

07000-B5140

O-RING

22

707-52-90851

BUSHING

23

707-75-11040

RING, SNAP

24

01010-82085

BOLT

25

707-88-75310

WASHER

26

707-36-15260

PISTON

27

707-44-15150

RING, PISTON

28

707-39-15110

RING, WEAR

29

707-44-15911

RING

30

707-35-31000

RING, BACK-UP

31

07000-B5100

O-RING

32

01310-01216

SCREW

33

707-83-13010

VALVE

34

07750-01628

SPRING

35

707-87-14070

PLUG

36

07002-12034

O-RING

37

707-86-67920

TUBE

38

20D-62-17860

ELBOW

39

07372-21060

BOLT

40

01643-51032

WASHER

41

07372-21045

BOLT

42

01643-51032

WASHER

43

07000-13030

O-RING

44

07000-13035

O-RING

45

707-88-22670

BRACKET

46

707-88-21351

BAND

47

01010-81080

BOLT

48

01643-31032

WASHER

49

707-88-36130

PLATE

50

01643-31032

WASHER

51

01597-01009

NUT

52

07283-32738

CLIP, PIPE

53

07372-21035

BOLT

54

01643-51032

WASHER

55

707-88-33030

CAP

56

07371-30640

FLANGE, SPLIT

57

707-88-33040

CAP

58

07371-31049

FLANGE, SPLIT

|$59

707-99-59680

SEAL KIT, HYDRAULIC CYLINDER
