Запчасти Komatsu PC290LC-10 P- КОНЕЧНАЯ ПЕРЕДАЧА (/) МОТОР ХОДА - ВНУТР. ЧАСТИ НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

207-27-00471

MOTOR, TRAVEL

|$1

708-8H-00351

MOTOR ASSEMBLY

1

708-8H-32120

SHAFT

2

708-8H-32150

BEARING

3

708-8H-32170

BEARING

4

708-8H-05050

SPACER KIT

|$6

NSS

SPACER, T= 1.6 MM

|$7

NSS

SPACER, T= 1.7 MM

|$8

NSS

SPACER, T= 1.8 MM

|$9

NSS

SPACER, T= 1.9 MM

|$10

NSS

SPACER, T= 2.0 MM

|$11

NSS

SPACER, T= 2.1 MM

|$12

NSS

SPACER, T= 2.2 MM

5

708-1F-12281

SEAL, OIL

6

708-8H-32160

SPACER

7

04065-07825

RING, SNAP

|$16

708-8H-04810

CYLINDER BLOCK ASSEMBLY

8

NSS

BLOCK, CYLINDER

9

NSS

VALVE, PLATE

10

708-18-13230

PIN

11

708-8H-33360

PIN

12

708-8H-33141

SPACER

13

708-8H-33750

SPRING

14

04065-06020

RING

15

708-8H-33512

RETAINER

16

708-8H-33340

RETAINER

17

708-8H-33650

PISTON SUBASSEMBLY

18

708-8H-33482

CAM, ROCKER

19

04260-02857

BALL

20

708-8H-34310

PISTON, REGULATOR

21

708-8H-34290

SPRING

22

708-8H-34151

SPRING

23

708-8K-14210

PLUG

24

07002-13334

O-RING

25

708-8H-35130

PLATE

26

708-8H-35180

DISC

27

708-8H-35141

PISTON, BRAKE

28

07000-15175

O-RING

29

07001-05175

RING, BACK-UP

30

07000-15195

O-RING

31

07001-05195

RING, BACK-UP

32

708-8H-35150

SPRING
